High Effective Atlas Copco Wireline Core Barrel N2 N3 With Latching System

1 sets
MOQ
Negotiate
ราคา
High Effective Atlas Copco Wireline Core Barrel N2 N3 With Latching System
คุณสมบัติ คลังภาพ รายละเอียดสินค้า ขออ้าง
คุณสมบัติ
ข้อมูลจำเพาะ
Name: Core Barrel
Type: Conventional Core Barrel
Style: Wireline Core Barrel
Materials: European 4145 Steel Casing
Model: Q Series Core Barrel NQ, HQ, PQ Wireline Core Barrel
Metric: Bristish Metric Core Barrel
Standards: T 2-66, T 2-76, T 2-86, T 2-101, T 2-116; T6-76, T6-86, T6-101, T6-116
Core Barrels: Boart Longyear Core Barrel
Sweden Core Barrel: Atlas Copco Core Barrel
Tools: Wireline Coring Tools
Q 3 Series: HQ 3, NQ 3, PQ 3 Core Barrels
Triple Core Barrel: BMLC, NMLC, HMLC Triple Tube Core Barrels
แสงสูง:

triple tube core barrel

,

drilling core barrel

ข้อมูลพื้นฐาน
สถานที่กำเนิด: Germany
ชื่อแบรนด์: ROSCHEN
ได้รับการรับรอง: ISO, CE
หมายเลขรุ่น: B N N2 N3 H H3
การชำระเงิน
รายละเอียดการบรรจุ: Wooden box
สามารถในการผลิต: 100 sets
รายละเอียดสินค้า

Atlas Copco Wireline core barrel N2 N3 NEW latching system Improve 30% Faster Penetration Rates




Thinner walls and tighter tolerances enable Roschen to offer a lighter weight core barrel, and when used with Roschen’s thin kerf bits, decreases the surface area for up to 30% faster penetration rates. These systems feature a number of unique innovations including ITIP valve for landing indication and integrated pump out for triple-tubes.


Roschen’s thin kerf coring systems offer many advantages for both surface and underground applications — the geologist can log a larger core sample from a similar sized hole and the driller is able to work under more ergonomic conditions. Contact your local Roschen representative to get more information.


Roschen recommends using only Roschen quality manufactured parts. Roschen does not guarantee the consistency or quality of other manufacturers.


Sizes / Systems:

System Hole Core
mm in mm in
A 48,0 1.89 27,0 1.06
B 59,9 2.36 36,4 1.43
N 75,7 2.98 47,6 1.88
H 96,1 3.78 63,5 2.5
P 122,6 4.83 85,0 3.35







Features:

1. Wireline system which affected the rod and core barrel design and incorporated the use of a wireline overshot.









2. Triple-tube system which effected the core barrel and the bit design and allowed for a second split inner tube to be used so that an undisturbed sample of very broken core could be viewed in its original state.


3. Thin kerf or light weight systems which effected the design and dimensions of the entire drill string to allow for a larger core sample to be retrieved at increased depths or in similar sized hole.
