M 6A Mission 60 Down The Hole Hammer for Submersible Drilling Rig

1pcs
MOQ
Negotiate
ราคา
M 6A Mission 60 Down The Hole Hammer for Submersible Drilling Rig
คุณสมบัติ คลังภาพ รายละเอียดสินค้า ขออ้าง
คุณสมบัติ
ข้อมูลจำเพาะ
Model: Donw The Hole Hammer
Name: Secoroc COP Hammer
Drills: Down The Hole Drilling, DTH Drilling
Machine: Hydraulic Crawler Drill Rig
Drillings: Water Well Drilling
Tools: Down The Hole Drilling Tools
Equipment: Surface Ground Core Drill Rig
แสงสูง:

dth drilling tools

,

down hole hammer

ข้อมูลพื้นฐาน
สถานที่กำเนิด: GERMANY CHINA
ชื่อแบรนด์: ROSCHEN
ได้รับการรับรอง: ISO,CE
หมายเลขรุ่น: ROS 64
การชำระเงิน
รายละเอียดการบรรจุ: Wooden Box
สามารถในการผลิต: 2000pcs
รายละเอียดสินค้า

M6A DTH Hammer (M6)

Mission 60 Down The Hole Hammer

M 6A DTH Hammer Mission 60 Down The Hole Hammer for Submersible Drilling Rig





DTH Hammer



The Down The Hole Hammer is an integral part of the submersible drilling rig and belongs to the working device of the downhole drilling rig. DTH Hammer are divided into low-pressure submersible impacters, stroke pressure dive impacters and high pressure dive impacters.



Widely used in metallurgy, coal, chemical, building materials are not busy mines and water conservancy, hydropower, roads, railways, defense, construction and other projects into the hole, suitable for dry and wet operation hole water wind and water mixture, and borehole gushing wet operation, reliable performance, is now the ideal drilling hole equipment.




The working principle of the impact: the beginning of the impact of the stroke, the piston and the valve are in the extreme position, the pressure through the valve cover and the seat of the radial hole into the cylinder chamber, pushing the piston high-speed downward movement impact drill. When the piston row to the bushing of the spline groove is closed, the lower chamber pressure began to rise, so the upper end of the piston hole out of the air column, so that the upper cavity through the atmosphere, the pressure is reduced, the end of the working stroke. When the piston after the impact of the tail of the drill, the valve due to its upper and lower pressure effect, the commutation, the piston repeated return stroke movement.




Basic Info
Model NO M6, Mission 60
Mining Object Mining, Mineral Exploration Core Drilling
Origin Germany,China
Type Drilling Machine
Trademark Roschen
HS Code 84123100
Mining Object Mining, Ore Machinery, Stone Quarry
Usage Use Together with DTH Button Bits
Aplication DTH Drilling. Coal Mining, Quarry
Drill Diameter 65-305mm
Transport Package Ply wood Box






Product Description:


It is a kind of high air pressure DTH Hammer without footvalve, our newest design. It is also one of the most advanced DTH Hammers in the world.


It has the following advantages:

1. Out of the trouble of foot valve fracture and expansion and contraction.

2. Lower energy consumption and higher impact frequency. The drilling speed is 15%-30% higher than the one with foot valve.

3. Simple structure, reliable parts, long life, easy and cheap maintenance.

4. Lower air and oil consumption. The oil consumption is about 10% lower than the one with foot valve.




Length (exclude bit) Weight (exclude bit) External Diameter Bit Shank Hole Range Connection Thread
1161 mm 90.00 kg Φ146 mm Mission 60 Φ155mm ~ Φ203mm API 3 1/2'' Reg
Working Pressure Impact rate at 0.5 MPa Recommended Rotary Speed Air Consumption
1.0 MPa 1.8 MPa 2.4 MPa
1.0 ~ 2.5 MPa 25 Hz 20-30 rpm 9 m³/min 18 m³/min 26 m³/min






DTH hammers Specifications
Hammer Size Bit Shank ROSCHEN Code Connection Thread Suitable bit Working pressure Air consumption
2" BR2 ROS 11 ROS 22 RD50 box ¢70-¢90mm 0.7-1.75Mpa 0.7Mpa 4.5m3/min
1.0Mpa 4m3/min
1.4Mpa 5m3/min
3" DHD3.5 ROS 32 API 2 3/8" Reg ¢90-¢110mm 1.0-1.5Mpa 1.0Mpa 4.5m3/min
COP32/COP34
M30 1.5Mpa 9m3/min
4" DHD340 ROS 34 API 2 3/8" Reg ¢110-¢135mm 1.0-2.5Mpa 1.0Mpa 6m3/min
COP44
QL40
SD4 1.8Mpa 10m3/min
M40 2.4Mpa 15m3/min
5" DHD350 ROS 52 ROS 54 API 2 3/8"Reg/API 3 1/2" Reg ¢135-¢155mm 1.0-2.5Mpa 1.0Mpa 9m3/min
COP54
QL50
SD5 1.8Mpa 15m3/min
M50 2.4Mpa 23m3/min
6" DHD360 ROS 62 ROS 64 API 3 1/2" Reg ¢155-¢190mm 1.0-2.5Mpa 1.0Mpa 10m3/min
COP64
QL60
SD6 1.8Mpa 20m3/min
M60 2.4Mpa 28.5m3/min
8" DHD380 ROS 82 ROS 84 API 4 1/2" Reg ¢195-¢254mm 1.0-2.5Mpa 1.0Mpa 15m3/min
COP84
QL80 1.8Mpa 26m3/min
SD8 2.4Mpa 34m3/min
10" SD10 ROS 100 API 6 5/8" Reg ¢254-¢311mm 1.0-2.5Mpa 1.0Mpa 22m3/min
Numa100 1.8Mpa 40m3/min
ROS 100 2.4Mpa 55m3/min
12" DHD1120 ROS 120 API 6 5/8" Reg ¢305-¢445mm 1.0-2.5Mpa 1.0Mpa 30m3/min
SD12 1.8Mpa 56m3/min
Numa120 2.4Mpa 78m3/min
Notes: Metzke, Remet thread is available!
