N100A NUMA 100 DTH Drilling Tools , Hydrological Wells dth hammer drilling

1~5pcs
MOQ
N100A NUMA 100 DTH Drilling Tools , Hydrological Wells dth hammer drilling
คุณสมบัติ คลังภาพ รายละเอียดสินค้า ขออ้าง
คุณสมบัติ
ข้อมูลจำเพาะ
Model: Donw The Hole Hammer
Name: Secoroc COP Hammer
Drills: Down The Hole Drilling, DTH Drilling
Machine: Hydraulic Crawler Drill Rig
Drillings: Water Well Drilling
Tools: Down The Hole Drilling Tools
Equipment: Surface Ground Core Drill Rig
แสงสูง:

dth drilling tools

,

down hole tools

ข้อมูลพื้นฐาน
สถานที่กำเนิด: Germany,China
ชื่อแบรนด์: ROSCHEN
ได้รับการรับรอง: ISO,CE
หมายเลขรุ่น: ROS100
การชำระเงิน
รายละเอียดการบรรจุ: Wooden box
สามารถในการผลิต: 1000pcs
รายละเอียดสินค้า

N100A DTH Hammer



NUMA100 Down The Hole Hammer


N100A DTH Hammer NUMA 100 Down The Hole Hammer For Hydrological Wells Drilling




DOWN THE HOLE DRILLING HAMMERS



DTH hammer is used for drilling holes through a wide range of rock types, the variety of which continues to extend well beyond the original conception of early blast hole drilling.



Down-the-Hole refers to where the hammer action occurs when compared to drifter hammers, which hammer on top of the drill string. The DTH hammer piston always makes direct contact with the drill bit and there is generally no loss of transmitted energy as the hammer drills deeper, as is the case with drifter (top hammer) rigs.



Roschen offers a wide range of DTH hammers suitable for a variety of drilling operations. Our Down the Hole hammers provide the most versatile and cost effective rock drilling method.



Basic Info
Model NO NUMA 100
Mining Object Mining
Origin Germany,China
Type Drilling Machine
Trademark Roschen
HS Code 84123100







Description:


It is a kind of high air pressure DTH Hammer without footvalve, our newest design. It is also one of the most advanced DTH Hammers in the world.




Advantages:


1. Out of the trouble of foot valve fracture and expansion and contraction.


2. Lower energy consumption and higher impact frequency. The drilling speed is 15%-30% higher than the one with foot valve.


3. Simple structure, reliable parts, long life, easy and cheap maintenance.


4. Lower air and oil consumption. The oil consumption is about 10% lower than the one with foot valve.






Length (exclude bit) Weight (exclude bit) External Diameter Bit Shank Hole Range Connection Thread
1545 mm 305.00 kg Φ226 mm NUMA100 Φ254mm ~ Φ311mm API 6 5/8'' Reg
Working Pressure Impact rate at 0.5 MPa Recommended Rotary Speed Air Consumption
1.0 MPa 1.8 MPa 2.4 MPa
1.0 ~ 2.5 MPa 20 Hz 15 ~ 25 rpm 22 m³/min 40 m³/min 65 m³/min






DTH hammers Specifications
Hammer Size Bit Shank ROSCHEN Code Connection Thread Suitable bit Working pressure Air consumption
2" BR2 ROS 11 ROS 22 RD50 box ¢70-¢90mm 0.7-1.75Mpa 0.7Mpa 4.5m3/min
1.0Mpa 4m3/min
1.4Mpa 5m3/min
3" DHD3.5 ROS 32 API 2 3/8" Reg ¢90-¢110mm 1.0-1.5Mpa 1.0Mpa 4.5m3/min
COP32/COP34
M30 1.5Mpa 9m3/min
4" DHD340 ROS 34 API 2 3/8" Reg ¢110-¢135mm 1.0-2.5Mpa 1.0Mpa 6m3/min
COP44
QL40
SD4 1.8Mpa 10m3/min
M40 2.4Mpa 15m3/min
5" DHD350 ROS 52 ROS 54 API 2 3/8"Reg/API 3 1/2" Reg ¢135-¢155mm 1.0-2.5Mpa 1.0Mpa 9m3/min
COP54
QL50
SD5 1.8Mpa 15m3/min
M50 2.4Mpa 23m3/min
6" DHD360 ROS 62 ROS 64 API 3 1/2" Reg ¢155-¢190mm 1.0-2.5Mpa 1.0Mpa 10m3/min
COP64
QL60
SD6 1.8Mpa 20m3/min
M60 2.4Mpa 28.5m3/min
8" DHD380 ROS 82 ROS 84 API 4 1/2" Reg ¢195-¢254mm 1.0-2.5Mpa 1.0Mpa 15m3/min
COP84
QL80 1.8Mpa 26m3/min
SD8 2.4Mpa 34m3/min
10" SD10 ROS 100 API 6 5/8" Reg ¢254-¢311mm 1.0-2.5Mpa 1.0Mpa 22m3/min
Numa100 1.8Mpa 40m3/min
ROS 100 2.4Mpa 55m3/min
12" DHD1120 ROS 120 API 6 5/8" Reg ¢305-¢445mm 1.0-2.5Mpa 1.0Mpa 30m3/min
SD12 1.8Mpa 56m3/min
Numa120 2.4Mpa 78m3/min
Notes: Metzke, Remet thread is available!







For more information please contact:







ROSCHEN INC.
ROSCHEN GROUP LIMITED
ROSCHEN HOLDINGS LIMITED



Skype: ROSCHEN.TOOL , ROSCHEN_GROUP



WeChat: +86-137 6419 5009 ; +86-135 8585 5390



WhatsApp: +86-137 6419 5009 ; +86-135 8585 5390



Email: roschen@roschen.com ; roschen@roschen.net



Website: http://www.roschen.net ; http://www.roschen.cn



http://www.roschen.com ; http://www.roschengroup.com
